It’s been 3 years since our post “Hashtags in FileMaker”, so we decided to give the demo a bit of a refresh and add a few features. To review, the hashtag demo utilizes a web viewer to display the user-defined “hashtags”, which then call back to FileMaker to either add, delete, or perform a find for the hashtag. Since its inception in FileMaker 14, the web viewer object hasn’t had any notable features added to it, but between FM 14 and FM 17, the web viewer seems to have become more integrated into a layout. Specifically, you no longer need to click into a web viewer in order to make it “active”, which makes for a much more seamless user interface.
I’ve made a number of small enhancements to this demo file, listed below:
-
Added a global container to store the “delete” image icon used to create the delete button for each hashtag
-
Added Find-mode functionality to search by hashtag
-
Added options to auto-complete and select hashtags from a drop-down in both Browse and Find modes
-
Removed the option to use the hash character while typing the hashtag, similar to Twitter’s interface
-
Fixed a bug when deleting hashtags
-
Updated interface
Since the web viewer is separated from fields in the database, we can’t exactly reproduce Twitter’s interface for adding and deleting hashtags inline with other text. We could grab the text entered into the web viewer with each keystroke, then perform the actions based on the keystroke code, but it’s still not quite as seamless as we’d like, so for this example, we’re separating the hashtags into their own field, then defining the specific addition/deletion/find call-back actions in the html.
For creating the refactored delete button, we’re storing the delete image in a global container field, then using FileMaker’s Base64 functions to take the image in the container, then encode it to be used as a string in the HTML. Utilizing Base64Encode allows the developer to drop in any image for the deletion button, and reuse it multiple times throughout the web viewer, all without adding much complexity.
The demo file included with this post is free for the taking, so feel free to download the file and use it to your liking. As always, if you have any questions or would like assistance customizing the Hashtag Demo for your solution, please contact us.
FAQ
A hashtag in FileMaker is a user-defined keyword or label that helps in categorizing and organizing records within the database. It’s typically used in a text field to mark records for easy searching and grouping.
Use a specific text field to store hashtags. Users can add multiple hashtags per record. This method facilitates quick filtering and finding of records based on shared topics or attributes by performing searches on these specific hashtags.
Best practices include keeping hashtags concise and relevant, using consistent formatting (like always starting with a hash character), and avoiding spaces. Regularly review and standardize hashtags to maintain database integrity and usability.
Yes, you can search records by hashtags by performing a find operation on the text field where hashtags are stored. Use the hashtag directly in your search query to filter records that include that specific tag.
To ensure consistency, establish a guideline or a controlled vocabulary for hashtag use. Consider creating a value list or a script that suggests existing hashtags as users type, to prevent the creation of redundant or incorrect tags.
